Shaders: 199 WebGPU Components for Interactive Effects

Shaders is an open-source WebGPU component library for creating GPU effects in plain JavaScript, React, Vue, Svelte, and Solid.

Each effect is a component, and components can be stacked or nested into one canvas-rendered composition.

Props can update after initialization, follow pointer input, animate over time, or read values from another layer.

The registry cunrrently contains 199 components, including the structural Group component.

Features

• 199 canonical registry components across 10 categories.
• Plain JavaScript, React, Vue, Svelte, and Solid entry points.
• Layer stacking, nesting, blending, opacity, visibility, and masking.
• Runtime prop updates through shader.update().
• Time-driven, pointer-driven, and layer-driven prop values.
• Layer transforms and component-aware bounding boxes.
• Row and column flow layout for Group.
• Output color-space and tone-mapping controls.
• Custom shader definitions with TypeScript and WGSL.
• WebGPU availability checks and terminal failure reporting.
• Browser editor, CLI, MCP integration, and agent skill.

How To Use Shaders

Installation

Plain JavaScript projects import the runtime from shaders/js. The package carries TypeGPU as a runtime dependency. Framework bindings use optional peer dependencies for React, Vue, Svelte, or Solid.

npm install shaders

Basic Usage

Give the canvas an explicit CSS size before initialization. Components render in array order. A later layer draws above earlier layers unless nesting changes the composition.

<canvas id="hero-shader"></canvas>

#hero-shader {
  display: block;
  width: 100%;
  height: 400px;
}

import { createShader } from 'shaders/js'
const canvas = document.getElementById('hero-shader')
const shader = await createShader(canvas, {
  components: [
    {
      type: 'LinearGradient',
      id: 'background',
      props: {
        colorA: '#0f172a',
        colorB: '#7c3aed',
        angle: 45,
      },
    },
    {
      type: 'CursorTrail',
      props: {},
    },
  ],
})

Update Component Props At Runtime

Assign an id to any component that needs programmatic updates. update() accepts a partial props object. A static prop can also be replaced with a compatible dynamic prop driver.

shader.update('background', {
  angle: 120,
  colorB: '#06b6d4',
})

shader.update('background', {
  angle: {
    type: 'auto-animate',
    mode: 'loop',
    outputMin: 0,
    outputMax: 360,
    speed: 0.1,
  },
})

Nest Components

Components that require child content can process a nested component tree.

const shader = await createShader(canvas, {
  components: [
    {
      type: 'Blur',
      props: {
        intensity: 8,
      },
      children: [
        {
          type: 'LinearGradient',
          props: {
            colorA: '#111827',
            colorB: '#a855f7',
          },
        },
      ],
    },
  ],
})

Shared Layer Controls

Blend Modes

• Basic: normal
• Darkening: multiply, darken, colorBurn, linearBurn
• Lightening: screen, lighten, colorDodge, linearDodge
• Contrast: overlay, softLight, hardLight
• Difference: difference, exclusion
• Color: hue, saturation, color, luminosity
• Color-space blending: normal-oklab, normal-oklch

Opacity And Visibility

opacity accepts values from 0 to 1.

visible: false removes the layer from the active composition. A layer with opacity: 0 continues to render. Hidden layers can act as mask sources.

Mask Layers

Give the mask component an id, set visible: false, and reference that ID through maskSource.

maskType accepts:

• alpha
• alphaInverted
• luminance
• luminanceInverted

const shader = await createShader(canvas, {
  components: [
    {
      type: 'Circle',
      id: 'mask',
      props: {
        radius: 0.8,
        visible: false,
      },
    },
    {
      type: 'LinearGradient',
      props: {
        colorA: '#22d3ee',
        colorB: '#7c3aed',
        maskSource: 'mask',
        maskType: 'alpha',
      },
    },
  ],
})

Transform Layers

shader.update('background', {
  transform: {
    offsetX: 0,
    offsetY: 0,
    rotation: 12,
    scale: 0.9,
    anchorX: 0.5,
    anchorY: 0.5,
    edges: 'transparent',
  },
})

Position Components With boundingBox

boundingBox is active only on components that declare bounding-box behavior. Partial objects are accepted and merged with a full-frame box. Dimensions use px or uv. A UV value of 1 represents the full size of the relevant canvas axis. lockAspect is an editor resize hint and has no renderer effect.

origin accepts top-left, top-center, top-right, center-left, center, center-right, bottom-left, bottom-center, and bottom-right.

shader.update('background', {
  boundingBox: {
    x: { unit: 'uv', value: 0.1 },
    y: { unit: 'uv', value: 0.1 },
    width: { unit: 'uv', value: 0.8 },
    height: { unit: 'uv', value: 0.8 },
    rotation: 12,
  },
})

Group Flow Layout

Group can arrange measurable child components in a row or column. Set absolute: true on a child that should keep its own position outside the parent flow.

const shader = await createShader(canvas, {
  components: [
    {
      type: 'Group',
      props: {
        flow: {
          mode: 'row',
          gap: 24,
          align: 'center',
          anchor: 'center',
        },
      },
      children: [
        {
          type: 'Circle',
          props: {
            radius: 0.12,
            color: '#22d3ee',
          },
        },
        {
          type: 'Circle',
          props: {
            radius: 0.12,
            color: '#a855f7',
          },
        },
      ],
    },
  ],
})

Dynamic Props

auto-animate

auto-animate changes a numeric or dimensional prop over time. easing applies to ping-pong mode.

mouse-position

mouse-position drives a position prop from the pointer.

mouse

mouse maps one pointer axis to a numeric or dimensional prop.

map

map uses another component’s rendered alpha or luminance as the control signal. The source component needs an id.

Output Color Space And Tone Mapping

colorSpace and toneMapping belong to the third ShaderOptions argument.

Output Color Space

• p3-linear
• srgb

Tone Mapping

• linear
• reinhard
• cineon
• aces
• agx
• neutral
• hable
• unreal

const shader = await createShader(
  canvas,
  {
    components: [
      {
        type: 'LinearGradient',
        props: {
          colorA: '#ff6b6b',
          colorB: '#4ecdc4',
        },
      },
    ],
  },
  {
    colorSpace: 'srgb',
    toneMapping: 'aces',
  }
)

JavaScript API Reference

PresetConfig

ComponentConfig

createShader()

createShader(
  canvas: HTMLCanvasElement,
  preset: PresetConfig,
  options?: ShaderOptions
): Promise<ShaderInstance>

ShaderOptions

Terminal onError values include unsupported, no-adapter, no-device, init-failed, device-lost, out-of-memory, gpu-error, render-failed, limit-exceeded, unrecoverable, and rebuild_failed.

• components?: GpuShaderDefinition[]: Custom definitions referenced by type.
• colorSpace?: 'p3-linear' | 'srgb': Output color space.
• toneMapping?: 'linear' | 'reinhard' | 'cineon' | 'aces' | 'agx' | 'neutral' | 'hable' | 'unreal': Tone-mapping operator.
• disableTelemetry?: boolean: Disables telemetry collection. Default: false.
• enablePerformanceTracking?: boolean: Enables performance tracking. Default: false.
• isPreview?: boolean: Preview-mode flag used by preview integrations.
• onReady?: () => void: Runs when rendering is ready.
• onError?: (reason: string) => void: Receives recoverable device-loss information and terminal GPU failures.
• observeElement?: boolean: Controls automatic resize and visibility observation. Default: true.
• gpu?: { device: GPUDevice; adapter: GPUAdapter }: Uses an externally managed WebGPU device and adapter.

ShaderInstance

WebGPU Availability And Debug Helpers

Environment-controlled debugging can use globalThis.__SHADERS_DEBUG__ = true or localStorage.setItem('shaders:debug', '1').

createPreview()

createPreview(canvas, options) creates a watermarked preview from a preview token or preset ID. Exactly one of shader or presetId is required. The returned instance includes the ShaderInstance methods plus setConfiguration(configuration).

createSharedDevice()

Normal shader instances reuse a lazily created page-level WebGPU device. createSharedDevice() is intended for application-owned device management, a specific adapter power preference, or interoperation with another WebGPU renderer.

powerPreference defaults to high-performance. The function returns null when a WebGPU device cannot be created.

createSharedDevice(options?: {
  powerPreference?: GPUPowerPreference
}): Promise<{ device: GPUDevice; adapter: GPUAdapter } | null>

Framework Entry Points

Framework entry points expose <Shader>, <Preview>, <CustomShader>, and the generated component exports for that framework. WebGPU rendering begins in the browser. SSR integrations need client-side initialization.

Built-In Components

• Textures (54): Aurora, Beam, Blob, BlockNoise, BlueNoise, BrickPattern, Checkerboard, Chevron, ColorWheel, ConicGradient, CurlNoise, DiamondGradient, DotGrid, ErosionNoise, FallingLines, FloatingParticles, FlowingGradient, FractalNoise, GaborNoise, Godrays, Grid, HexGrid, HTMLInCanvas, ImageTexture, IsometricCubes, LinearGradient, Marble, MeshGradient, MultiPointGradient, PerlinNoise, Plasma, Prism, RadialGradient, Ripples, Scratches, SimplexNoise, SineWave, SolidColor, Spiral, Strands, Stripes, StudioBackground, SunBurst, Swirl, Text, TriangularGrid, Truchet, VideoTexture, Voronoi, Waveform, WaveletNoise, Weave, WebcamTexture, WorleyNoise.
• Shapes (16): Arc, Circle, Crescent, Cross, Ellipse, Flower, Heart, Line, Parallelogram, Polygon, Ring, RoundedRect, Star, Teardrop, Trapezoid, Vesica.
• Shape Effects (23): BrushedMetal, CarbonFiber, Chrome, Crystal, Emboss, Frost, Glass, Goo, Heatmap, Hologram, Holographic, Irradiance, LightEdge, LiquidMetal, Nebula, Neon, Obsidian, Particles, Plastic, SmokeFill, ThinFilm, Voxels, Water.
• Stylize (31): Ascii, Chalkboard, ChromaticAberration, CompressionArtifacts, ContourLines, CRTScreen, DataMosh, Dither, DropShadow, Engraving, FilmGrain, Glitch, Glow, GradientMap, Halftone, KeyFrames, LensDistortion, LensFlare, LightLeak, ObjectTracker, Paper, ParticleField, Pixelate, ReflectivePlane, Sparkle, Stone, TimeTrail, VHS, Vignette, Watercolor, Wool.
• Interactive (16): Boids, ChromaFlow, CursorRipples, CursorTrail, Fog, GridDistortion, InkFlow, Liquify, MagneticFilings, ParticleFlow, PixelSort, PixelThrow, ReactionDiffusion, Shatter, Smoke, SmokeFlow.
• Distortions (22): BarShift, Bend, Bulge, ConcentricSpin, CornerPin, DisplacementMap, Flip, FlowField, FlutedGlass, Form3D, GlassTiles, Kaleidoscope, Mirror, Perspective, PolarCoordinates, RectangularCoordinates, Repeater, Spherize, Stretch, Surface3D, Twirl, WaveDistortion.
• Transitions (13): BarnDoors, BlockDissolve, CheckerWipe, DiamondWipe, IrisWipe, LinearWipe, NoiseDissolve, PagePeel, RadialWipe, RandomBars, RippleWipe, SliceWipe, VenetianBlinds.
• Blurs (9): AngularBlur, Blur, BokehBlur, ChannelBlur, DiffuseBlur, LinearBlur, ProgressiveBlur, TiltShift, ZoomBlur.
• Adjustments (14): BrightnessContrast, Duotone, Exposure, FilmStock, Grayscale, HueShift, Invert, Posterize, Saturation, Sharpness, Solarize, Tint, Tritone, Vibrance.
• Utilities (1): Group.

Custom Shader Components

Custom components use defineShader from shaders/std. A definition declares its component name, props, and pixel operation.

WGSL is the stable custom-shader option. The std primitives API is experimental.

import {
  defineShader,
  wgsl,
  transformColor,
  transformPosition,
} from 'shaders/std'
export const Halo = defineShader({
  name: 'Halo',
  props: {
    color: {
      default: '#ffd166',
      transform: transformColor,
    },
    center: {
      default: { x: 0.5, y: 0.5 },
      transform: transformPosition,
    },
    radius: {
      default: 0.6,
    },
  },
  paint: wgsl`
    let d = length((uv - center) * vec2f(aspect, 1.0)) / radius;
    return vec4f(color.rgb, 1.0 - smoothstep(0.8, 1.0, d));
  `,
})

Plain JavaScript Custom Components

Plain JavaScript passes custom definitions through ShaderOptions.components.

import { createShader } from 'shaders/js'
import { Halo } from './halo'
await createShader(
  document.querySelector('canvas'),
  {
    components: [
      {
        type: 'Halo',
        props: {
          color: '#ffffff',
          radius: 0.7,
        },
      },
    ],
  },
  {
    components: [Halo],
  }
)

Framework Custom Components

Framework projects mount a defineShader() result through <CustomShader>.

Design Editor, CLI, And AI Integrations

The browser editor builds component trees, edits props, drives values from pointer or timeline controls, and exports framework code.

CLI

npx shaders
npx shaders connect
npx shaders install
npx shaders search "liquid chrome hero background"
npx shaders preview <name>
npx shaders update

Agent Skill

The agent skill can be installed directly.

npx shaders skill

MCP

The MCP installer configures compatible AI coding agents like Claude Code.

npx shaders@latest install-mcp
